The curing agent is provide with a filter device,high pressure safety protection device in the pipe line,to ensure the operating more safety.
◆The curing agent is provide with a filter device, high pressure safety protection device in the pipe line, to ensure the operating more safety.
◆The system is a closed system, put an end to the air and avoid curing agent contacting with the air and curing, to ensure that the media flow stability.
◆The high pressure valve of base material pump, curing agent pump and proportional pump adopt zero leakage of special alloy grinding, has a unique and convenient adjustable proportioning mechanism, ensure the bi-component sealant almost harsh ratio requirements.
◆The mixing system used precision stainless steel mixer, mixing mandrel, with the specially designed unidirectional needle valve, to ensure the mixing evenly.
◆The curing agent is provide with a filter device, high pressure safety protection device in the pipe line, to ensure the operating more safety.
◆The system is a closed system, put an end to the air and avoid curing agent contacting with the air and curing, to ensure that the media flow stability.
◆The high pressure valve of base material pump, curing agent pump and proportional pump adopt zero leakage of special alloy grinding, has a unique and convenient adjustable proportioning mechanism, ensure the bi-component sealant almost harsh ratio requirements.
◆The mixing system used precision stainless steel mixer, mixing mandrel, with the specially designed unidirectional needle valve, to ensure the mixing evenly.
| Mixing ratio | 6:1-14:1 |
| Material drum | 55gallon(200L) |
| Firming agent | 5gallon(20L) |
| Maximum gas consumption | 0.8M/min |
| Working pressure | 30Mpa |
| Output | 4-10L/min |
| Supply gas pressure | 0.6-1.0Mpa |
| Overall dimension | 1100*950*1980mm |
| Weight | 650kg |
Shandong Truetec Company is a manufacturer of glass processing machines, such as insulating glass.
